HA-2520, HA-2522, HA-2525 comprise a series of operational amplifiers delivering an unsurpassed combination of specifications for slew rate, bandwidth and settling time.
These dielectrically isolated amplifiers are controlled at close loop gains greater than 3 without external compensation.
In addition, these high performance components also provide low offset current and high input impedance.
Features
• High Slew Rate: 120V/µs
• Fast Settling: 200ns
• Full Power Bandwidth：2MHz
• Gain Bandwidth (AV ≥3) ： 20MHz
• High Input Impedance ：100MΩ
• Low Offset Current ：10nA
• Compensation Pin for Unity Gain Capability
• Pb-Free Available (RoHS Compliant)
Applications
• Data Acquisition Systems
• RF Amplifiers
• Video Amplifiers
• Signal Generators
