FC050S6R5 and FC150S6R5
Power Modules:dc-dc Converters; 18 to 36 Vdc input, 6.5 Vdc Output; 50 W to 150 W
Features
--Wide input range
--High efficiency: 84% typical
--Parallel operation with load sharing
--Low profile: 12.7 mm (0.5 in.)
--Complete input and output filtering
--Constant frequency
--Case ground pin
--Input-to-output isolation
--Remote sense
--Remote on/off
--Short-circuit protection
--Output over voltage clamp
--UL Recognized,CSA Certified, TUV Licensed
Applications
--Distributed and redundant power architectures
--Telecommunications
Options
--Output voltage set-point adjustment (trim)
Description
The FC05036R5 and FC150S6R5 Power Modules are dc-dc converters that operate over an input voltage range of 18 Vdc to 36 Vdc and provide a precisely regulated dc output, The outputs are fully isolated from the inputs, allowing versatile polarity configurations and grounding connections. The modules have maximum power ratings from 50 W to 150 W at a typical full-load efficiency of 84%.
Built-in filtering, for both the input and output of each device, eliminates the need for external filters. Two or more modules may be paralleled with forced load sharing for redundant or enhanced power applications. The package, which mounts on a printed-circuit board, accommodates a heat sink for high-temperature applications
