• Complies with the CoaXPress v1.1 Camera Standard (1) • Supports up to 68 Meters of Cable at 6.25 Gbps Using High-Quality Coax • Supports up to 212 Meters of Cable at 1.25 Gbps Using High-Quality Coax • Single-Chip Solutions for Both the Camera Side and the Frame Grabber Side, Making a Bidirectional Connection Over a Single 75Ω Coax Cable • Full-Duplex, Bidirectional Data Channel - Downlink Speeds from 1.25 Gbps up to 6.25 Gbps; Differential Interfacing Straightforward with Internal Termination Resistors - Uplink Supporting 21 Mbps, Allowing Nanoseconds Precise Triggering Events Driven by the Frame Grabber • Supports Power Distribution Over the Coax up to 900 mA, Powering the Camera Through the Same Coax Transporting Data Signals • Low Power Consumption (
• High-Definition/High-Bandwidth Links to Cameras
• Machine Vision for Semiconductor Chips and
Display Panel Inspection Systems
• Military, Aerospace, Medical Applications
• Broadcast and Surveillance Camera Systems
• Traffic License Plate and Monitoring Systems
• High-Speed Inspection Systems for Food Inspection,
Bottling Inspection, Panel Inspection, etc.
• Any application requiring a single coax cable
which carries power, video data and camera
control stream
The EQCO62T/R20(2)
chipset is a driver/equalizer
chipset that forms a bidirectional, full-duplex
communication link over a single coax cable.
The EQCO62T/R20 chipset is designed to transport up
to 6.25 Gbps over the downlink channel and to transport 21 Mbps over the uplink channel. The
EQCO62T20 is designed to transmit the downlink signal up to 6.25 Gbps and receive the uplink signal. The
EQCO62R20 is designed to receive the downlink signal up to 6.25 Gbps and to transmit the uplink signal.
Power can be transferred over the same cable via
external inductors.
The chipset is designed to work with several types of
75Ω coaxial cables, including leg
