FEATURES
+0.5 LSB DNL
+1 LSBINL
16-Bit Monotonic
Low Noise: 12 nV/Hz
Low Power: IDD =2 uA
Analog Power Supply: +27 V to +5.5 V
2 mA Full-Scale Current:+20%, with VREF = 10 V
Settling Time: 0.5 us
4-Quadrant Multiplying Reference
Reference Bandwidth: 10 MHz
Reference Input:+10 V
Reference Dynamics:-105 THD
SSOP-28 Package
Industry-Standard Pin Confiquration
APPLICATIONS
Automatic Test Equipment
Instrumentation
Digitally Controlled CalibrationIndustrial Control PLCs
DESCRIPTION
The DAC8820 multiplying digital-to-analog converterDAC) is designed to operate from a single 2.7-V to55-V supply.
The applied external reference input voltage VREFdetermines the full-scale output current. An internafeedback resistor (Re) provides temperature trackingfor the full-scale output when combined with anexternal, voltage-to-current (I/V) precision amplifier.
