FEATURES
- Two 8-Bit DACs In A Single Chip
- Adjustment-Free Internal CMOS Amplifiers
- Single or Dual Supply Operation
- TTL Compatible Over Full Vop Range
- 5 Microsecond Settling Time
- Fast Interface Timing
- Improved Resistance to ESD
- Fits AD/PM-7528 And AD/PM-7628 SocketsAvailable In Small Outline Package
- -40°C to +85°C for the Extended industrial TemperatureRange
- Available In Die Form
APPLICATIONS
- Automatic Test Equipment
- Process/industrial Controls
- Energy Controls
- Programmable instrumentation
- Disk Drive SystemsMulti-Channel Microprocessor-Controlled Systems
GENERAL DESCRIPTIONThe DAC-8229isadual 8-bit, voltage output, multiplying CMOSD/A converter. lts reference input accepts a +2.5V signal, in-verts and delivers it to the outputwith an internal amplifier. It canalso accept-10Vat Vae with a corresponding +10V output (themaximum positive input signal that it can accept is +2.5V).The DAC-8229 was designed to operate with dual supplies;however, it can be operated with a single supply by connectingContinued
