General Description
The current-feedback CLC410 is a fast-settling，wideband.monolithic op amp with fast disable/enable feature. Designed for low-gain applications (Av=±1 to ±8), the CLC410 consumes only 160mW of power(180mW max) yet provides a -3dB bandwidth of 200MHz (Av= +2) and 0.05% settling in 12ns(15ns max). Plus，the disable feature provides fast turn-on (100ns) and turn-off (200ns). In addition, the CLC410 offers both high performance and stability without compensation even at a gain of + 1.
The CLC410 provides a simple, high-performance solution for video switching and distribution applications, especially where analo g buses benefit from use of the disable function to “multiplex”signals onto the bus. Differential gain/phase of 0.01%/0.01° provide high fidelity and the 70mA output current offers ample drive capability.
The CLC410's fast settling, low distortion, and high drive capabilities make it an ideal ADC driver. The low 160mW quiescent power consumption and very low 40mW disabled power consumption suggest use where power is critical and/or “system off" power consumption must be minimized.
Features
-- -3dB bandwidth of 200MHz
--0.05% settling in 12ns
--Low power, 160mW (40mW disabled)
--Low distortion, -60dBc at 20MHz
--Fast disable (200ns)
--Differential gain/phase: 0.01%/0.01°
--±1 to ±8 closed-loop gain range
Applications
--Video switching and distribution
--Analog bus driving (with disable)
-- Low power “standby” using disable
--Fast, precision A/D conversion
--D/A current-to-voltage conversion
--IF processors
--High-speed communications
