Description
The AT29C256 is a five-volt-only in-system Flash programmable and erasable read only memory (PEROM). Its 256K of memory is organized as 32,768 words by 8 bits. Manufactured with Atmel’s advanced nonvolatile CMOS technology, the device offers access times to 70 ns with power dissipation of just 275 mW.
Features
• Fast Read Access Time – 70 ns
• 5-volt Only Reprogramming
• Page Program Operation
– Single Cycle Reprogram (Erase and Program)
– Internal Address and Data Latches for 64 Bytes
• Internal Program Control and Timer
• Hardware and Software Data Protection
• Fast Program Cycle Times
– Page (64 Byte) Program Time – 10 ms
– Chip Erase Time – 10 ms
• DATAPolling for End of Program Detection
• Low-power Dissipation
– 50 mA Active Current
–300 µA CMOS Standby Current
• Typical Endurance > 10,000 Cycles
• Single 5V ±10% Supply
• CMOS and TTL Compatible Inputs and Outputs
• Commercial and Industrial Temperature Ranges
