| General Description The AOD11S60 & AOI11S60 have been fabricated using the advanced αMOSTM high voltage process that is designed to deliver high levels of performance and robustness in switching applications. By providing low RDS(on), Qg and EOSS along with guaranteed avalanche capability these parts can be adopted quickly into new and existing offline power supply designs. Product Summary VDS @ Tj,max 700V IDM 45A RDS(ON),max 0.399Ω Qg,typ 11nC Eoss @ 400V 2.7µJ 100% UIS Tested 100% Rg Tested |
