| General Description The AOT290L/AOB290L uses Trench MOSFET technology that is uniquely optimized to provide the most efficient high frequency switching performance. Power losses are minimized due to an extremely low combination of RDS(ON) and Crss.In addition, switching behavior is well controlled with a soft recovery body diode.This device is ideal for boost converters and synchronous rectifiers for consumer, telecom, industrial power supplies and LED backlighting. Product Summary VDS 100V ID (at VGS=10V) 140A RDS(ON) (at VGS=10V) < 3.5mΩ (< 3.2mΩ∗) 100% UIS Tested 100% Rg Tested |
