| GENERAL DESCRIPTION The Am27C512 is a 512-Kbit, ultraviolet erasable programmable read-only memory. It is organized as 64K words by 8 bits per word, operates from a single +5 V supply, has a static standby mode, and features fast single address location programming. Products are available in windowed ceramic DIP packages, as well as plastic one time programmable (OTP) PDIP and PLCC packages. DISTINCTIVE CHARACTERISTICS Fast access time — Speed options as fast as 55 ns Low power consumption — 20 µA typical CMOS standby current JEDEC-approved pinout Single +5 V power supply ±10% power supply tolerance standard 100% Flashrite™ programming — Typical programming time of 8 seconds Latch-up protected to 100 mA from –1 V to VCC+ 1 V High noise immunity Versatile features for simple interfacing — Both CMOS and TTL input/output compatibility — Two line control functions Standard 28-pin DIP, PDIP, and 32-pin PLCC packages |
