| DESCRIPTION The AIC1680 is an accurate, ultra-low power consumption voltage detector IC, fabricated with advanced CMOS process. The AIC1680 consists of a comparator, a voltage reference unit, a resistor divider, two output drivers, and a hysteresis circuit. FEATURES Ultra-Low Quiescent Current. 1.5V to 10.0V Input Voltage Operation. Flexible Detection Voltage Setting 0.1V Step in the Range of 1.6V to 6.0V High Detection Voltage Accuracy at ±2.5%. Built-In Detection Voltage Hysteresis. Three Output Types: N-ch, P-ch and CMOS. Space Saving Packages: TO-92, SOT-89, SOT-23 and SOT23-5. APPLICATIONS Battery Checker for Battery-Operated Systems. CPU & Logic Circuit Reset. Memory Back-up Circuit. Level Discriminator. Power Failure Detector. |
