AUDIO FREQUENCY AMPLIFIER，SWITCHINGPNP SILICON EPITAXIAL TRANSISTOR
SMD Type Silicon PNP Epitaxia 2SA1411 SOT-23 +0.1 2.9-0.1 +0.1 0.4-0.1 Transistors IC Features Very high DC current gain:hFE=500 to 1600. High VEBO Voltage:VEBO=-10V +0.1 2.4-0.1 Unit: mm +0.1 1.3-0.1 1 +0.1 0.95-0.1 +0.1 1.9-0.1 2 0.55 0.4 3 +0.05 0.1-0.01 +0.1 0.97-0.1 1.Base 2.Emitter 3.collector Absolute Maximum Ratings Ta = 25 Parameter Collector-base voltage Collector-emitter voltage Emitter-base voltage Collector current Total power dissipation at 25 ambient temperature Tj Tstg 150 -55 to +150 Symbol VCBO VCEO VEBO IC PT Rating -25 -25 -10 -150 200 Unit V V V mA mW Junctio.
